Concepts and concept sets
Concepts
Concepts describe information in a person's medical record, such as a condition, a prescription they are taking, a doctor's visit and other information. Every concept comes from the OHDSI standardized vocabularies and has the following properties:
- ID - A unique numeric identifier of the concept.
- Code - Identifiers from the source vocabularies.
- Name - Each concept has one name in English.
- Vocabulary - Unique case-sensitive alphanumeric ID, generally following the abbreviated name of the vocabulary
- Standard/Non-standard Concept - Standard concept is the one concept representing the meaning of each clinical event. Non-standard concepts are not used to represent clinical events but are present in the vocabularies.
- Domain - Domains are subject areas such as conditions, drugs, measurements, and so on.
- Class - Concept class name used to create additional structure to the concepts within each vocabulary.
- Validity - Vocabularies keep getting updated and this field indicates whether the concept is valid or deprecated.
Concept sets
A concept set is a reusable collection of concepts that describes one clinical idea, for example "type 2 diabetes" or "metformin". You use concept sets in Data Exploration, in cohort definitions, and in analyses.
A concept set does more than list concepts. For each concept you choose whether to include its Descendants in the vocabulary hierarchy, whether non-standard source codes Mapped to it count, and whether to Exclude it. This way, "all forms of diabetes except gestational diabetes" fits into one set.
Find concepts and create a concept set
- Select Concepts in the navigation bar. The page has two tabs: Concept Sets lists the saved concept sets, Search searches the vocabulary.
- On the Search tab, search for a term, for example "atrial fibrillation". Use Filters to narrow the results by domain, vocabulary, class or standard concept.
- Select the concepts you want. In the Add with strip, choose the options for the new rows, for example Descendants, and add them. A new concept set opens with these concepts.
- Enter a name for the concept set and select Save.
Select a concept name to open its details: its attributes, its place in the hierarchy, related concepts, and how often it occurs in the data source.
Work with a concept set
The concept set editor has the following tabs:
| Tab | What it shows |
|---|---|
| Selected | The concepts you added, with the Descendants, Mapped and Exclude options per row. |
| Included | All concepts the set resolves to, including descendants and mapped concepts. Check this list before you use the set in a cohort. |
| Source Codes | The source codes, such as ICD-10 codes, that map to the included concepts. |
| Search | The vocabulary search, to add more concepts. |
| Recommend | Concepts that are often used together with the concepts in the set. |
| Compare | Differences to another concept set. |
You can also add many concepts at once with Paste IDs, Import by source code and Import JSON, and tidy the set with Optimize.
To open a saved concept set, select it on the Concept Sets tab. You can only save changes to concept sets you own or have been given write access to.
More in the ATLAS user manual
- Chapter 5 "Vocabulary search": search syntax, the result table, and concept details.
- Chapter 6 "Concept sets": all editor tabs, bulk import, tags, recommendations, comparison, and starting from a phenotype library.
